Size DN50—DN600
Nominal Pressure PN10/PN16
Working Temperature -10°C~120°C
Suitable Medium Chemicals,air,water,steam,oil, acids,salts,etc
Performance:
Nominal pressue (MPa) | 1.0 | 1.6 | |
Nominal diameter(mm) | Shell | 50-600 | 50-600 |
Test pressure | Seal | 1.5 | 2.4 |
(MPa) | 1.1 | 1.76 | |
Applicable temperature | 150 | ||
Applicable medium | Fresh water, Sewage, Sea water, Air, Vapor, Food, Medicine, Oils, Acids, | ||
Operating mode | manual, worm gear, pneumatic, electric, etc. | ||
Standard:
Design & Manufacture | Flange Connection | Face to Face Dimension | Test&Inspection |
MSS SP70 | BS5152 | BS5152 |
Material List:
NO. | Part Name | Material |
1 | Body | Cast Iron/Ductile Iron |
2 | Body Seat Ring | Cast Bronze |
3 | Reaction Member | Brass |
4 | Disc | Cast Bronze |
5 | Gasket | Brass |
6 | Swivel Nut | Cast Brass |
7 | Boll | Steel |
8 | Body Gasket | Graphite |
9 | Bonnet | Cast Iron |
10 | Packing | Graphite |
11 | Packing Gland | Cast Brass |
12 | Gland Follower | Ductile Iron |
13 | Gland Follower Bolts | Steel |
14 | Gland Follower Nuts | Steel |
15 | Stem | Brass |
16 | Yoke Busing | Cast Bronze |
17 | Screw | Steel |
18 | Handwheel | Cast Iron |
19 | Identification | Steel |
20 | Handwheel nut | Ductile Iron |
