| Quantity: | |
|---|---|
Tianjin, China
1000PCS/Per Day
L/C, T/T
Low Pressure (Pn<1.6mpa)
Normal Temperature (-40°C<T<120°C)
Soft Sealed
Casting
DIN, BS, ANSI, JIS
Industrial Usage, Water Industrial Usage
Dn50-Dn600 2"-24" 50mm-600mm
Cast Iron, Ductile Iron, Steel
TFW
Plywood Case
CE
Tianjin China
84818040
Oil Water
Manual
Lug Support
Double-Eccentric Sealing
Force Sealed
Orbit
| STANDARD MATERIAL OF MAIN PARTS | ||
| NO. | PART | MATERIAL |
| 1 | Body | Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel |
| 2 | Seat | NBR,EPDM, Viton,Neoprene,HYPALON,Silicon |
| 3 | Shaft | Stainless Steel416,316,304 |
| 4 | Disc | Ductile Iron+Ni,CF8,CF8M,Bronze |
| 5 | Pin | Stainless Steel |
| 6 | Bushing | PTFE,Bronze |
| 7 | O-Ring | NBR,EPDM |
|
One-piece wafer body style or full lug style for terminal service. Both body styles offer bidirectional sealing as standard in conformance,Cast iron and stainless steel can be selected,Customizable product color and logo
Wide Variety Of Disc Material Choices
Precision machined and hand polished disc to provide a minimum torque and longer seat life.Customizable color material
Actuator Mounting Flange OR Handle
The top flange is drilled as per EN ISO 5211 to accommodate direct mounting of a wide range of actuators.Operating handles with different materials and colors
Wide Choice Of Seating MaterialsSmooth finished disc flats mate with seat to give a highly efficient primary seal that prevents leakage into the shaft area.Customizable seat material, such as EPDM,NBR,PTFE and so on.
Optional Electric Actuated and Pneumatic Actuated
COMPANY INTRODUCTION
TIANJIN TANGFA WATTS VALVE CO., LTD. is a professional valve manufacturer with high quality products and internal management standards. It has a high reputation in the foundry industry. Our company has a modern factory, advanced manufacturing processing and testing equipment, strong technical force.We have More than 200 employees, more than 30 years of professional experience, skilled technicians and operators, the products passed ISO 9001:2015 and CE certification, our main products are concentric butterfly valve,eccentric butterfly valve, tripleeccentric butterfly valve, soft seat gate valve, ball valve, check valve, Ystrainer, rubber joints, etc. With product quality and perfect service system, it is sold in dozens of countries and regions such as Europe, America, Southeast Asia, Middle East, Australia, North Africa, South Korea, Hong Kong,Taiwan and so on. Our company's purpose is: professional and technical support, perfect after-sales service!
We welcome you to contact us for more information and look forward to working with you!
FAQ
1. Q: Are you a manufacturer or trading company ?
A: we are valve manufacturer and factory ,and not trading company.
2. Q: Do you have agent or representative abroad?
A: We do not have agent abroad,please contact us to purchase valves
from TIANJIN TANGFA WATTS VALVE CO., LTD.. directly.
3. Q: What's your product range?
A: We can produce Butterfly valve,Gate valve,Check valve,Y strainer,Rubber Joint
by ISO/ANSI/DIN/JIS/ EN/GOST/AS standard.
4. Q: Is there any stock in your factory? and how about your lead time?
A: We stock valves with normal sizes. The lead time depends on your quantity,
generally 30-35 days.
5. Q: Which countries do you export to ?
A: We export directly to vast majority of countries in the world.
6. Q: What certificates will you provide ?
A: We can provide CE/ ISO / WRAS.
7. Q:After-sales service
A:18 months year warranty for all kinds of products.
As an experienced manufacturer, you can rest assured of the quality and sales service.
8.Q: Payment
A:T/T, L/C, OA, D/P, D/A.
9.Q:Transportation
A:Transported by DHL, UPS, EMS, FEDEX, SF, by Air, by Sea.
10. Q:Do you provide free sample?
A:Free sample is OK for us.
11. Q:Do you accept custom design on size?
A:Yes, if the size is reasonable
| STANDARD MATERIAL OF MAIN PARTS | ||
| NO. | PART | MATERIAL |
| 1 | Body | Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel |
| 2 | Seat | NBR,EPDM, Viton,Neoprene,HYPALON,Silicon |
| 3 | Shaft | Stainless Steel416,316,304 |
| 4 | Disc | Ductile Iron+Ni,CF8,CF8M,Bronze |
| 5 | Pin | Stainless Steel |
| 6 | Bushing | PTFE,Bronze |
| 7 | O-Ring | NBR,EPDM |
|
One-piece wafer body style or full lug style for terminal service. Both body styles offer bidirectional sealing as standard in conformance,Cast iron and stainless steel can be selected,Customizable product color and logo
Wide Variety Of Disc Material Choices
Precision machined and hand polished disc to provide a minimum torque and longer seat life.Customizable color material
Actuator Mounting Flange OR Handle
The top flange is drilled as per EN ISO 5211 to accommodate direct mounting of a wide range of actuators.Operating handles with different materials and colors
Wide Choice Of Seating MaterialsSmooth finished disc flats mate with seat to give a highly efficient primary seal that prevents leakage into the shaft area.Customizable seat material, such as EPDM,NBR,PTFE and so on.
Optional Electric Actuated and Pneumatic Actuated
